2" - 2.8" - 3.5" - 5" - 7" - 10.1"

Are you looking for a TFT display with touch panel as "Ready-to-Run"? Our Smart Touch Panels are suitable for a wide range of applications in industry, medical technology and the consumer sector.

Brilliant colours, paired with a powerful controller for graphics and I/O functionalities. Plus perfect service directly from Germany and a genuine availability guarantee.

- Extreme bright wit more than 1000cd/m²

- Fast Graphics Controller with powerful graphic commands

- Easy screen design with f.o.c. tool "uniTFTDesigner"

- Standalone application

- Demo board available with p/n EA DEMOPACK

- 2", 2.8", 3.5", 4.3" - Data Sheet uniTFTs

Powerful control units for monitoring and control.

Any object can be placed, moved and deleted at any time. Fonts can be zoomed and rotated without loss. Selected Windows character sets are stored directly in the display. Thanks to automatic ASCII and Unicode switching, all systems are flexibly supported; Chinese characters included.
Elegant effects for fading in and out or flying in are already integrated. Stylesheets can be used to create uniform designs. Images can be embedded as JPEG, PNG or SVG (also transparent), sound can be played in the form of MP3. Together with the integrated and battery-buffered time base, events can be documented together with the help of a time stamp or processes can be controlled completely autonomously.

5", 7", 10,1" - Data Sheet uniTFT

The new EA uniTFT displays provide various interfaces to the outside world. An USB interface is available for flashing the onboard memory and debugging or also for normal operation. To run the display there are also an SPI, RS-232 and I²C bus interface available.
4 analogue inputs and one PWM output enable processing of analog signals. 8 up to136 digital I/O take over a wide range of control tasks. A video input (uniTFT only) delivers images, which can be displayed on the screen directly or stored on the integrated micro SD card (uniTFT only).
The long-term availability and the high quality requirements testify to the target markets of industry, automotive and medicine.

With the graphic tool uniTFTDesigner specially adapted to the possibilities of this display, screen layouts and user interfaces are created easyly. Insert touch areas, text and picutres by drag&drop operation. The properties of an object (position, size, angle, transparency) are quickly adapted. Just like the standard stylesheets (fill color, border, font style).
Including a fully simulator, macro editor and debugger. With the debugger tool you can develop and test all projects without any hardware.

Download uniTFTDesigner

Optionally, for all displays are starter packs available. EA QUICKuniTFT for the 5", 7" and 10.1" displays and EA DEMOPACK for the 2", 2.8", 3.5" and 4.3" displays. The EA QUICKuniTFT comes together with:

- a connection board for 12-24V

- power adaptor for 110V/230V~

- a suitable USB cable for the mini-USB plug on the display

- the uniTFTDesigner layout tool for Windows

- lots of examples and documentation
