Data Logger for temperature and humidity

Temperature, Humidity, Event, Voltage, 4~20mA, CO

DISPLAY VISIONS provides the data logger EA SYLOG-USB-2 to monitor and record ambient temperature, relative humidity and dew point. It is ideal for applications in the pharmaceutical and food industry, transportation and logistics and general laboratory use. The device can simply be inserted into a PC USB port for fast, uncomplicated analysis of the data which has been logged. Drivers for current versions of Windows are provided.

Others are for event, voltage, 4~20mA or CO carbonmonoxide.

Here you do find a flyer as a pdf file.

More than 32.000 Readings

The EA SYLOG-USB-2 captures temperature and relative humidity data simultaneously and can store up to 16,382 readings. It also calculates the dew point for each reading. The data logging intervals can be in the range between 10 seconds and 12 hours and are user selectable. The date and time when logging shall start can also be pre-programmed also.

The built-in battery supplies enough energy for more than 1 year.

Data Display and Export

Software is supplied for displaying the results on the computer screen in graphics format. The graphs can also be formatted for printing. The data can be converted into a variety of standard formats and exported for further processing.

Here's a link for a free download: ELWin V7.5.

Lithium Power

The data logger has a wide operating temperature range of -35°C to +80°C which is equivalent to -31°F - +176°F when the data logger is set to the Fahrenheit scale. The device also records the relative humidity between 0% and 100% and calculates the dew point. The data loggers come with a long-life, replaceable lithium battery which normally lasts more than 1 year before needing replacement. A plastic cap provides IP67 protection, keeping out water and dust even during operation.

LED Indicator

Colored LED indicators display the current device status. The LEDs also indicate whether pre-set minimum or maximum temperature thresholds have been exceeded, which is important to verify the integrity of the cooling chain in the food and pharmaceutical industries.

Temperature

Product	Description	Temperature Range	Humidity	Readings
EA SYLOG-USBLT	Low Cost USB Temperature Data Logger, 2 free definable alarm levels	-10 ... +50°C	--	4,080
EA SYLOG-USB-1	USB Temperature Data Logger, IP67 protection, 2 free definable alarm levels	-35 ... +80°C	--	up to 16,382

Humidity & Temperature

Product	Description	Temperature Range	Humidity	Readings
EA SYLOG-USB-2	Humidity & Temperature USB Data Logger, IP67 protection, free definable alarm levels for humidity and temperature	-35 ... +80°C	0 ... 100% RH	up to 2x 16,382
EA SYLOG-USB-2+	Humidity & Temperature USB Data Logger with enhanced accuracy, IP67 protection, free definable alarm levels for humidity and temperature	-35 ... +80°C	0 ... 100% RH	up to 2x 16,382
EA SYLOG-U-2LCD	Humidity & Temperature USB Data Logger with LC display and IP67 protection, free definable alarm levels for humidity and temperature	-35 ... +80°C	0 ... 100% RH	up to 2x 16,382

Thermocouple

Product	Description	Temperature	Readings
EA SYLOG-USB-TC	USB Temperature Data Logger with K-Type Thermocouple Probe, Compatible with K, J & T-Type Thermocouples	-200 ... +1350°C K-Type -200 ... +1190°C J-Type -200 ... +390°C T-Type	up to 32,512
EA SYLOG-USB-TC-LCD	USB Temperature Data Logger with K-Type Thermocouple Probe, Compatible with K, J & T-Type Thermocouples, with LC display		up to 32,512
